大靶面远心镜头
| 产品系列 |
工作距离
(mm)
|
倍率
(x)
|
相机靶面
(mm)
|
有效光圈 |
O/I
(mm)
|
TV 畸变
(%)
|
分辨率
(μm)
|
景深
(mm)
|
同轴光 |
接口
|
| AKY-110R2-35GF-1.5x | 110 | 1.5 | 35 | 6.5-22.1 | 340.2 | ≤0.01 | 2.9-9.9 | 0.23-0.79 | — | F |
| AKY-110R2-43GF-2x | 110 | 2.0 | 43.5 | 8.0-22.4 | 388.0 |
≤0.02 |
2.7-7.5 | 0.16-0.45 | — |
F |
| AKY-110R2-43GTF-2x | 110 | 2.0 | 43.5 | 8.0-22.4 | 388.0 | ≤0.02 | 2.7-7.5 | 0.16-0.45 | √ | F |
| AKY-110R2-43GF-3x | 110 | 3.0 | 43.5 | 14.8-21.9 | 372.8 |
≤0.01 |
3.3-4.9 | 0.13-0.19 | — |
F |
| AKY-110R2-43GTF-3x | 110 | 3.0 | 43.5 | 14.8-21.9 | 372.8 | ≤0.01 | 3.3-4.9 | 0.13-0.19 | √ | F |
| AKY-80R4-43CGTM | 80 | 5.0 | 43.5 | 14.8-22.0 | 399.8 |
≤0.01 |
1.98-2.95 | 0.05-0.07 | √ | M58 |
| AKY-80R4-43CGM | 80 | 5.0 | 43.5 | 14.8-22.0 | 399.8 | ≤0.01 | 1.98-2.95 | 0.05-0.07 | — | M58 |
| AKY-130R2-35GF-1x | 130 | 1.0 | 35 | 6.6-21.8 | 328.0 |
≤0.02 |
4.4-14.6 | 0.52-1.74 | — |
F |
