红外远心镜头
| 产品系列 |
工作距离
(mm)
|
倍率
(x)
|
相机靶面
(mm)
|
有效光圈 |
O/I
(mm)
|
TV 畸变
(%)
|
分辨率
(μm)
|
景深
(mm)
|
同轴光 |
接口
|
波长范围
(mm)
|
| AKY-18R2-2/3GTC-7.5x-IR | 18 | 7.5 | 2/3" | 18.7 | 182 | ≤0.01 | 3 | 0.03 | √ | C | 700-1200 |
| AKY-30R2-2/3TC-1.5x-IR | 30 | 1.5 | 2/3" | 8.7 | 182 |
≤0.01 |
7 | 0.31 | √ | C | 700-1200 |
| AKY-65R3-2/3GTC-4x-IR | 65 | 4.0 | 2/3" | 18.7 | 225 | ≤0.01 | 3.5 | 0.06 | √ | C | 700-1200 |
| AKY-80R2-2/3C-4x-IR | 80 | 4.0 | 2/3" | 8.7 | 229 |
≤0.01 |
4 | 0.067 | — | C | 700-1200 |
| AKY-80R2-2/3TC-4x-IR | 80 | 4.0 | 2/3" | 18.7 | 229 | ≤0.01 | 4 | 0.067 | √ | C | 700-1200 |
| AKY-80R2-2/3C-6x-IR | 80 | 6.0 | 2/3" | 8.7 | 250 |
≤0.01 |
4 | 0.044 | — | C | 700-1200 |
| AKY-80R2-2/3TC-6x-IR | 80 | 6.0 | 2/3" | 18.7 | 250 | ≤0.01 | 4 | 0.044 | √ | C | 700-1200 |
| AKY-80R2-2/3C-8x-IR | 80 | 8.0 | 2/3" | 8.7 | 272 |
≤0.01 |
4 | 0.033 | — | C | 700-1200 |
| AKY-80R2-2/3TC-8x-IR | 80 | 8.0 | 2/3" | 18.7 | 272 | ≤0.01 | 4 | 0.033 | √ | C | 700-1200 |
| AKY-110R3-1.1GTC-1.5x-IR | 110 | 1.5 | 1.1" | 10.0-22.0 | 275 |
≤0.01 |
8.0-17.6 | 0.36-0.78 | √ | C | 700-1200 |
| AKY-110R3-1.1GC-1.5x-IR | 110 | 1.5 | 1.1" | 10.0-22.0 | 275 | ≤0.01 | 8.0-17.6 | 0.36～0.78 | — | C | 700-1200 |
| AKY-210R2-2/3TC-1x-IR | 210 | 1.0 | 1/2" | 12.5 | 440 |
≤0.01 |
16 | 1 | √ | C | 900-1100 |
| AKY-210R2-2/3TC-8x-IR | 210 | 8.0 | 1.1" | 50.0 | 500 | ≤0.01 | 8 | 0.306 | — | C | 900-1100 |
| AKY-220R2-2/3C-4x-IR | 220 | 4.0 | 2/3" | 23.5 | 417 |
≤0.01 |
9.68 | 0.12 | — | C | 800-1500 |
| AKY-65R2-2/3TC-1.5x-SWIR | 65 | 1.5 | 2/3" | 10.3 | 158 | ≤0.01 | 13 | 0.37 | √ | C | 900-1700 |
| AKY-110R2-43GF-2x-SWIR | 110 | 2.0 | 43 | 8.0-20.1 | 389 |
≤0.10 |
7.6-19.0 | 0.16-0.40 | — | F | 900-1700 |
| AKY-110R2-43GTF-2x-SWIR | 110 | 2.0 | 43 | 8.0-20.1 | 389 | ≤0.10 | 7.6-19.0 | 0.16-0.40 | √ | F | 900-1700 |
| AKY-110R2-43GF-2.5x-SWIR | 110 | 2.5 | 43 | 12.5-31.7 | 360 |
≤0.60 |
9.45-24.0 | 0.16-0.41 | — | F | 900-1700 |
| AKY-110R2-43GTF-2.5x-SWIR | 110 | 2.5 | 43 | 12.5-31.7 | 360 | ≤0.61 | 9.45-24.0 | 0.16-0.41 | √ | F | 900-1700 |
