1.1寸靶面超清微距镜头
| 产品系列 |
工作距离
(mm)
|
放大倍率
(x)
|
相机靶面 | 光圈系数 |
焦距
(mm)
|
TV 畸变
(%)
|
MTF
(Ip/mm)
|
像元大小
(μm)
|
接口 |
镜头尺寸
(mm)
|
滤光片尺寸
(mm)
|
| AKW-16R4-1.0C |
150-550 |
0.095x~0.029 |
1.0 ” |
4.0 |
16 |
≤0.07 |
200 |
2.4 |
C |
φ32x40 |
M25.5x0.5 |
| AKW-25R4-1.0C |
200-700 |
0.122x-0.035 |
1.0 ” |
4.0 |
25 |
≤0.08 |
200 |
2.4 |
C |
φ32x35 |
M25.5x0.5 |
| AKW-35R4-1.0C |
150-550 |
0.274x-0.063 |
1.0 ” |
4.0 |
35 |
≤0.09 |
200 |
2.4 |
C |
φ32x41 |
M25.5x0.5 |
| AKW-25R4-1.1C |
65-400 |
0.32x-0.06 |
1.2” |
1.8-16 |
25 |
≤0.10 |
200 |
2.4 |
C |
φ42x62 |
M35.5x0.5 |
| AKW-35R4-1.1C |
145-590 |
0.26x-0.06 |
1.2" |
1.8-16 |
35 |
≤0.11 |
200 |
2.4 |
C |
φ35x43 |
M30.5x0.5 |
| AKW-40R3-1.2C |
75-144 |
0.30x-1.0 |
1.2" |
4.5-32 |
43 |
≤0.01 |
150 |
3.5 |
C |
φ44x79 |
M30.5x0.5 |
| AKW-50R4-1.1C |
175-600 |
0.29x-0.06 |
1.2" |
2.0-16 |
50 |
≤0.10 |
200 |
2.4 |
C |
φ40x70 |
M35.5x0.5 |
| AKW-75R4-1.1C |
200-500 |
0.464x-0.163 |
1.2" |
2.8-16 |
75 |
≤0.035 |
200 |
2.4 |
C |
φ40x82 |
M37x0.75 |
| AKW-90R4-1.1C |
325-400 |
0.45-0.33 |
1.2" |
2.8-16 |
90 |
≤0.08 |
200 |
2.4 |
C |
φ40x96 |
M34x0.5 |
| 产品系列 |
最近工作距离
(mm)
|
最大倍率
(x)
|
视野大小
(mm)
|
最远工作距离
(mm)
|
最小倍率
(x)
|
视野大小
(mm)
|
| AKW-16R4-1.0C | 150 | 0.095 | 134.7*101.1 | 550 | 0.029 | 441.4*331.0 |
| AKW-25R4-1.0C | 200 | 0.122 | 104.9*78.7 | 700 | 0.035 | 365.7*274.3 |
| AKW-35R4-1.0C | 150 | 0.274 | 46.7*35 | 550 | 0.063 | 203.2*152.4 |
| AKW-25R4-1.1C | 65 | 0.32 | 44.1*32.2 | 400 | 0.06 | 235.0*171.7 |
| AKW-35R4-1.1C | 145 | 0.25 | 56.4*41.2 | 590 | 0.06 | 235.0*171.7 |
| AKW-40R3-1.2C | 75 | 1.0 | 14.1*10.3 | 144 | 0.3 | 47.0*34.3 |
| AKW-50R4-1.1C | 175 | 0.29 | 48.6*35.5 | 600 | 0.06 | 235.0*171.7 |
| AKW-75R4-1.1C | 200 | 0.464 | 30.4*22.2 | 500 | 0.163 | 86.5*63.2 |
| AKW-90R4-1.1C | 325 | 0.45 | 31.3*22.9 | 400 | 0.33 | 42.7*31.2 |
