高倍高分辨率大靶面线扫镜头
| 产品系列 |
工作距离
(mm)
|
倍率
(x)
|
相机靶面
(mm)
|
光圈系数 |
焦距
(mm)
|
TV 畸变
(%)
|
MTF
(Ip/mm)
|
像元
(μm)
|
镜头尺寸
(mm)
|
接口 |
匹配相机
|
| AKX-66R3-58V |
500-750 |
0.086-0.11 |
58 |
4.5-22 |
66 |
≤0.17 |
150 |
3.5 |
φ93x133 |
V70 |
16k 3.5μm/70M |
| AKX-90R3-67V-0.2x |
460-655 |
0.15-0.22 |
67 |
4.0-22 |
93 |
≤0.10 |
150 |
3.5 |
φ76x88 |
V70 | 16k 3.5μm/151M |
| AKX-90R3-67V-0.3x |
310-375 |
0.28-0.35 |
67 |
4.0-22 |
93 |
≤0.10 |
150 |
3.5 |
φ76x99 |
V70 |
16k 3.5μm/151M |
| AKX-90R3-67V-0.45x |
240-280 |
0.40-0.48 |
67 |
4.0-22 |
93 |
≤0.10 |
150 |
3.5 |
φ76x115 |
V70 | 16k 3.5μm/151M |
| AKX-90R3-62GV-0.7x |
180 |
0.70 |
62.5 |
2.8-22 |
98 |
≤0.01 |
150 |
3.5 |
φ84x170 |
V74 |
16k 3.5μm |
| AKX-90R3-62GV-1.75x |
96 |
1.75 |
62.5 |
2.8-22 |
98 |
≤0.02 |
150 |
3.5 |
φ84x230 |
V74 | 16k 3.5μm |
| AKX-110R5-84CGV-2.0x |
90 |
2.0 |
84 |
2.9-8.0 |
109 |
≤0.10 |
130 |
3.5 |
φ80x378 |
V70 |
23k 3.5μm/151M |
| AKX-120R5-84CGV-1.67x |
120 |
1.67 |
84 |
2.7-8.0 |
120 |
≤0.028 |
150 |
3.5 |
φ80x379 |
V70 | 23k 3.5μm/151M |
| AKX-120R5-82CGV-2.5x |
105 |
2.5 |
82 |
2.5-22 |
120 |
≤0.05 |
100 |
3.5 |
φ76x420 |
V70 |
23k 3.5μm/151M |
| AKX-120R5-82CGV-3.5x |
90 |
3.5 |
84 |
1.2-80 |
122.5 |
≤0.028 |
100 |
3.5 |
φ95x338 |
V92 | 23k 3.5μm/151M |
| AKX-135R3-82V-0.3x |
328 |
0.3 |
82 |
3.8-22 |
134 |
≤0.10 |
130 | 5 |
φ76x93 |
V70 |
16k 5μm1510M |
| AKX-135R3-82V-0.5x |
328 |
0.5 |
82 |
3.8-22 |
134 |
≤0.10 |
130 |
5 |
φ76x95 |
V70 | 16k 5μm/151M |
| AKX-135R3-82V-0.75x |
328 |
0.75 |
82 |
3.8-22 |
134 |
≤0.10 |
130 |
5 |
φ76x92 |
V70 |
16k 5μm/151M |
| 接口型号 |
延长环
|
延长环
|
延长环
|
更多
|
| AKJ-F | — | — | — | — |
| AKJ-M42 | AKJ-M42L5 | AKJ-M42L10 | AKJ-M42L20 | 可定制 |
| AKJ-M58 | AKJ-M58L5 | AKJ-M58L10 | AKJ-M58L20 | 可定制 |
| AKJ-M72 | AKJ-M72L5 | AKJ-M72L10 | AKJ-M72L20 | 可定制 |
| AKJ-M95 | — | AKJ-M95L10 | AKJ-M95L20 |
可定制 |
