2/3 HR CCTV LENS
| Model Name |
WD
(mm)
|
Magnification
(x)
|
IF | Fno |
EFL
(mm)
|
TV Distortion
(%)
|
MTF
(Ip/mm)
|
Pixel
(μm)
|
Mount |
Lens Size
(mm)
|
Filter Size
(mm)
|
| AKF-12R4-2/3C | 145 | 0.07 | 2/3” | 1.8-16 | 12 | ≤1.10 |
230 |
2.2 | C | φ32x40 | M25.5x0.5 |
| AKF-16R4-2/3C | 145 | 0.09 | 2/3” |
1.6-16 |
16 |
≤0.50 |
230 |
2.2 |
C |
φ32x42 |
M25.5x0.5 |
| AKF-25R4-2/3C | 145 | 0.15 | 2/3” | 1.6-16 | 25 | ≤0.08 |
230 |
2.2 | C | φ32x40 | M25.5x0.5 |
| AKF-35R4-2/3C | 195 | 0.16 | 2/3” |
2.0-16 |
35 |
≤0.10 |
230 |
2.2 |
C |
φ32x46 |
M25.5x0.5 |
| AKF-50R4-2/3C | 295 | 0.19 | 2/3” | 2.5-16 | 50 | ≤0.10 |
230 |
2.2 | C | φ30x60 | M25.5x0.5 |
|
Model Name |
Comparison of Different Target Field of View |
||
|
2/3"
|
1/2"
|
1.1"
|
|
| AKF-12R4-2/3C | 125.7*94.3 | 90.4*68.6 | / |
| AKF-16R4-2/3C | 97.8*73.3 | 71.1*53.3 | / |
| AKF-25R4-2/3C | 58.7*44.0 | 42.7*32.0 | / |
| AKF-16R4-2/3C | 55.0*41.3 | 40.0*30.0 | / |
| AKF-50R4-2/3C | 46.3*34.8 | 33.7*25.3 | / |
