1.1 ULTRA-CLEAR TELECENTRIC LENS
| Model Name |
WD
(mm)
|
Magnification
(x)
|
IF
|
Effective Fno |
O/I
(mm)
|
TV Distortion
(%)
|
Resolution
(μm)
|
DOF
(mm)
|
Coaxial Light
|
Mount |
| AKY-65R3-1.1GC-1x | 65 | 1.0 | 1.1" | 6.9-22.2 | 204 | ≤0.03 | 4.7-14.8 | 0.56-1.76 | — | C |
| AKY-65R3-1.1GTC-1x | 65 | 1.0 | 1.1" | 6.9-22.2 | 204 |
≤0.03 |
4.7-14.8 | 0.56-1.76 | √ | C |
| AKY-65R3-1.1GC-2x | 65 | 2.0 | 1.1" | 7.7-22.4 | 213.5 | ≤0.05 | 2.7-7.4 | 0.15-1.45 | — | C |
| AKY-65R3-1.1GTC-2x | 65 | 2.0 | 1.1" | 7.7-22.4 | 213.5 |
≤0.05 |
2.7-7.4 | 0.15-1.45 | √ | C |
| AKY-65R3-1.1GC-3x | 65 | 3.0 | 1.1" | 9.42-21.9 | 236 | ≤0.015 | 2.1-4.9 | 0.08-0.19 | — | C |
| AKY-65R3-1.1GTC-3x | 65 | 3.0 | 1.1" | 9.42-21.9 | 236 |
≤0.015 |
2.1-4.9 | 0.08-0.19 | √ | C |
| AKY-65R3-1.1GC-4x | 65 | 4.0 | 1.1" | 11.9-22.2 | 271 | ≤0.006 | 1.99-3.73 | 0.06-0.11 | — | C |
| AKY-65R3-1.1GTC-4x | 65 | 4.0 | 1.1" | 11.9-22.2 | 271 |
≤0.006 |
1.99-3.73 | 0.06-0.11 | √ | C |
| AKY-110R2-1.0C-0.5x | 110 | 0.5 | 1" | 7.5-22.0 | 298.8 | ≤0.05 | 10-29.5 | 2.38-7.03 | — | C |
| AKY-110R2-1.0TC-0.5x | 110 | 0.5 | 1" | 7.5-22.0 | 298.8 |
≤0.05 |
10-29.5 | 2.38-7.03 | √ | C |
| AKY-110R2-1.0C-1x | 110 | 1.0 | 1.1" | 10.6-22.1 | 253.8 | ≤0.012 | 7.1-14.8 | 0.85-1.76 | — | C |
| AKY-110R2-1.0TC-1x | 110 | 1.0 | 1" | 10.6-22.1 | 253.8 |
≤0.012 |
7.1-14.8 | 0.85-1.76 | √ | C |
| AKY-110R2-1.0C-1.5x | 110 | 1.5 | 1" | 10.1-22.1 | 275.2 | ≤0.012 | 4.5-9.9 | 0.36-0.79 | — | C |
| AKY-110R2-1.0TC-1.5x | 110 | 1.5 | 1" | 10.1-22.1 | 275.2 |
≤0.012 |
4.5-9.9 | 0.36-0.79 | √ | C |
| AKY-110R2-1.0C-2x | 110 | 2.0 | 1" | 10.1-22.4 | 293.9 | ≤0.02 | 3.4-7.5 | 0.20-0.44 | — | C |
| AKY-110R2-1.0TC-2x | 110 | 2.0 | 1" | 10.1-22.4 | 293.9 |
≤0.005 |
3.4-7.5 | 0.20-0.44 | √ | C |
| AKY-110R3-1.1GC-0.6x | 110 | 0.6 | 1.1" | 5.6-22.0 | 257 | ≤0.005 | 6.3-4.6 | 1.25-4.89 | — | C |
| AKY-110R3-1.1GTC-0.6x | 110 | 0.6 | 1.1" | 5.6-22.0 | 257 |
≤0.03 |
6.3-24.6 | 1.25-4.89 | √ | C |
| AKY-110R3-1.1GC-0.75x | 110 | 0.75 | 1.1" | 5.7-22.0 | 270.2 | ≤0.017 | 5.1-19.7 | 0.81-3.13 | — | C |
| AKY-110R3-1.1GTC-0.75x | 110 | 0.75 | 1.1" | 5.7-22.0 | 270.2 |
≤0.017 |
5.1-19.7 | 0.81-3.13 | √ | C |
| AKY-110R3-1.1GC-0.8x | 110 | 0.8 | 1.1" | 5.6-22.0 | 275 | ≤0.005 | 4.73-18.46 | 0.70-2.75 | — | C |
| AKY-110R3-1.1GTC-0.8x | 110 | 0.8 | 1.1" | 5.6-22.0 | 275 |
≤0.005 |
4.73-18.46 | 0.70-2.75 | √ | C |
| AKY-130R3-1.1GC-0.28x | 130 | 0.28 | 1.1" | 8.0-23.0 | 350 | ≤0.01 | 19.6-56.0 | 8.50-24.28 | — | C |
| AKY-130R3-1.1GC-0.45x | 130 | 0.45 | 1.1" | 5.6-15.7 | 319 |
≤0.005 |
8.5-24 | 2.30-6.50 | — | C |
| AKY-130R3-1.1GTC-0.45x | 130 | 0.45 | 1.1" | 5.6-15.7 | 319 | ≤0.005 | 8.5-24 | 2.30-6.50 | √ | C |
