2/3 ULTRA-CLEAR TELECENTRIC LENS
| Model Name |
WD
(mm)
|
Magnification
(x)
|
IF
|
Effective Fno |
O/I
(mm)
|
TV Distortion
(%)
|
Resolution
(μm)
|
DOF
(mm)
|
Coaxial Light
|
Mount |
| AKY-65R3-2/3GC-0.5x | 65 | 0.5 | 2/3” | 6.9-30.6 | 220 | ≤0.028 | 9.3-41.0 | 2.22-9.78 | — | C |
| AKY-65R3-2/3GTC-0.5x | 65 | 0.5 | 2/3” | 6.9-30.6 | 220 |
≤0.028 |
9.3-41.0 | 2.22-9.78 | √ |
C |
| AKY-65R3-2/3GC-1.0x | 65 | 1.0 | 2/3” | 7.0-28.3 | 167.3 | ≤0.036 | 4.7-19 | 0.56-2.27 | — | C |
| AKY-65R3-2/3GTC-1.0x | 65 | 1.0 | 2/3” | 7.0-28.3 | 167.3 |
≤0.035 |
4.7-19 | 0.56-2.27 | √ |
C |
| AKY-65R3-2/3GC-2.0x | 65 | 2.0 | 2/3” | 7.2-45.6 | 184 | ≤0.021 | 2.4-15.3 | 0.14-0.91 | — | C |
| AKY-65R3-2/3GTC-2.0x | 65 | 2.0 | 2/3” | 7.2-45.6 | 184 |
≤0.021 |
2.4-15.3 | 0.14-0.91 | √ |
C |
| AKY-65R3-2/3GC-3.0x | 65 | 3.0 | 2/3” | 9.4-46.9 | 229.3 | ≤0.012 | 2.1-10.5 | 0.08-0.42 | — | C |
| AKY-65R3-2/3GTC-3.0x | 65 | 3.0 | 2/3” | 9.4-46.9 | 229.3 |
≤0.012 |
2.1-10.5 | 0.08-0.42 | √ |
C |
| AKY-65R3-2/3GC-4.0x | 65 | 4.0 | 2/3” | 11.9-48.9 | 225 | ≤0.029 | 2.0-8.2 | 0.06-0.24 | — | C |
| AKY-65R3-2/3GTC-4.0x | 65 | 4.0 | 2/3” | 11.9-48.9 | 225 |
≤0.029 |
2.0-8.2 | 0.06-0.24 | √ |
C |
| AKY-55R5-2/3CGC-5.0x | 55 | 5.0 | 2/3” | 26.1 | 210 | ≤0.02 | 3.5 | 0.083 | — | C |
| AKY-55R5-CGTC-5.0x | 55 | 5.0 | 2/3” | 26.1 | 210 |
≤0.02 |
3.5 | 0.083 | √ |
C |
| AKY-55R5-CGC-8.5x | 55 | 8.5 | 2/3” | 35.5 | 267 | ≤0.01 | 2.8 | 0.039 | — | C |
| AKY-55R5-CGTC-8.5x | 55 | 8.5 | 2/3” | 35.5 | 267 |
≤0.01 |
2.8 | 0.039 | √ |
C |
| AKY-55R5-CGC-10.0x | 55 | 10.0 | 2/3” | 22.4 | 254 | ≤0.01 | 1.5 | 0.018 | — | C |
| AKY-55R5-CGTC-10.0x | 55 | 10.0 | 2/3” | 22.4 | 254 |
≤0.01 |
1.5 | 0.018 | √ |
C |
| AKY-35R6-CGC-20.0x | 37 | 20.0 | 2/3” | 28.6-88.5 | 299 | ≤0.02 | 0.96-2.97 | 0.006-0.018 | — | C |
| AKY-35R6-CGTC-20.0x | 37 | 20.0 | 2/3” | 28.6-88.5 | 299 |
≤0.02 |
0.96-2.97 | 0.006-0.018 | √ |
C |
| AKY-110R3-2/3GC-0.3x | 110 | 0.3 | 2/3” | 6.9 | 270 | ≤0.043 | 15.7 | 6.16 | — | C |
| AKY-110R3-2/3GTC-0.3x | 110 | 0.3 | 2/3” | 6.9 | 270 |
≤0.043 |
15.7 | 6.16 | √ |
C |
| AKY-65R3-2/3GC-NO.5x-F6 | 66 | 0.5 | 2/3” | 6 | 185 | ≤0.012 | 8 | 0.48 | √ | C |
