HIGH-RESOLUTION,LARGE-FORMAT LINE-SCAN LENS
| Model Name |
WD
(mm)
|
Magnification
(x)
|
IF
(x)
|
Fno |
EFL
(mm)
|
TV Distortion
(%)
|
MTF
(Ip/mm)
|
Pixel
(μm)
|
Lens Size
(mm)
|
Mount |
Adaptation Camera
|
| AKX-28R2-35M |
200 |
0.13 |
35 |
2.8-22 |
28 |
≤1.20 |
130 |
3.8 |
φ55x70 |
M39 |
8k 5μm/29M |
| AKX-35R2-43M |
1000 |
0.04 |
43 |
2.8-22 |
35 |
≤0.60 |
130 |
3.8 |
φ45x74 |
M39 | 8k 5μm/29M |
| AKX-40R2-43M |
200 |
0.30 |
43 |
4.0-22 |
40 |
≤0.07 |
130 |
3.8 |
φ46x75 |
M39 |
8k 5μm/29M |
| AKX-55R2-62M | 216 |
0.30 |
62.5 |
4.0-22 |
55 |
≤0.08 |
130 |
3.8 |
φ43x39 |
M39 | 12k 5μm/47M |
| AKX-60R2-67M |
270 |
0.25 |
67 |
4.0-22 |
60 |
≤0.10 |
130 |
3.8 |
φ43x39 |
M39 |
16k 3.5μm/47M |
| AKX-65R2-62M | 300 |
0.40 |
62.5 |
4.0-22 |
65 |
≤0.10 |
130 |
3.8 |
φ45x25 |
M39 | 12k 5μm/47M |
| AKX-80R2-62M | 1000 |
0.09 |
62.5 |
4.0-22 |
80 |
≤0.10 |
130 |
3.8 |
φ45x53 |
M39 |
12k 5μm/47M |
| AKX-100R2-82M | 400 |
0.40 |
82 |
4.0-22 |
100 |
≤0.10 |
130 |
3.8 |
φ55x60 |
M39 | 16k 5μm/151M |
| AKX-80R2-82LM | 223-477 |
0.2-0.5 |
82 |
4.0-22 |
84.6 |
≤0.08 |
100 |
5 |
φ45x77 |
M39 |
16k 5μm/151M |
| AKX-80R2-82HM | 133-220 |
0.5-1.0 |
82 |
4.0-22 |
83 |
≤0.05 |
100 |
5 |
φ55x74 |
M39 | 16k 5μm/151M |
| Interface Model |
Extension Ring
|
Extension Ring
|
Extension Ring
|
More
|
| AKJ-F | — | — | — | — |
| AKJ-M42 | AKJ-M42L5 | AKJ-M42L10 | AKJ-M42L20 | Customizing |
| AKJ-M58 | AKJ-M58L5 | AKJ-M58L10 | AKJ-M58L20 | Customizing |
| AKJ-M72 | AKJ-M72L5 | AKJ-M72L10 | AKJ-M72L20 | Customizing |
| AKJ-M95 | — | AKJ-M95L10 | AKJ-M95L20 |
Customizing |
