1/2 SR TELECENTRIC LENS
| Model Name |
WD
(mm)
|
Magnification
(x)
|
IF
|
Effective Fno |
O/I
(mm)
|
TV Distortion
(%)
|
Resolution
(μm)
|
DOF
(mm)
|
Coaxial Light
|
Mount |
| AKY-65R1-1/2C-0.8x | 65 | 0.8 | 1/2” | 14.3 | 170 | ≤0.01 |
12.0 |
1.79 | — | C |
| AKY-65R1-1/2TC-0.8x | 65 | 0.8 | 1/2” |
14.3 |
170 |
≤0.01 |
12.0 |
1.79 | √ |
C |
| AKY-65R1-1/2C-1x | 65 | 1.0 | 1/2” | 18.2 | 160 | ≤0.01 |
12.0 |
1.45 | — | C |
| AKY-65R1-1/2TC-1x | 65 | 1.0 | 1/2” |
18.2 |
160 |
≤0.01 |
12.0 |
1.45 | √ |
C |
| AKY-65R1-1/2C-2x | 65 | 2.0 | 1/2” | 17.6 | 143 | ≤0.02 | 5.9 | 0.35 | — | C |
| AKY-65R1-1/2TC-2x | 65 | 2.0 | 1/2” |
17.6 |
143 |
≤0.02 |
5.9 | 0.35 | √ |
C |
| AKY-65R1-1/2C-3x | 65 | 3.0 | 1/2” | 21.0 | 141.8 | ≤0.01 | 4.7 | 1.19 | — | C |
| AKY-65R1-1/2TC-3x | 65 | 3.0 | 1/2” | 21.0 | 141.8 |
≤0.01 |
4.7 | 1.19 | √ |
C |
| AKY-65R1-1/2C-4x | 65 | 4.0 | 1/2” | 26.2 | 147.5 | ≤0.01 | 4.4 | 0.13 | — | C |
| AKY-65R1-1/2TC-4x | 65 | 4.0 | 1/2” | 26.2 | 147.5 |
≤0.01 |
4.4 | 0.13 | √ |
C |
| AKY-65R1-1/2C-6x | 65 | 6.0 | 1/2” | 39.3 | 163.4 | ≤0.01 | 4.4 | 0.09 | — | C |
| AKY-65R1-1/2TC-6x | 65 | 6.0 | 1/2” | 39.3 | 163.4 |
≤0.01 |
4.4 | 0.09 | √ |
C |
| AKY-110R1-1/2C-0.8x | 110 | 8.0 | 1/2” | 15.9 | 255 | ≤0.01 | 13.3 | 1.98 | — | C |
| AKY-110R1-1/2TC-0.8x | 110 | 8.0 | 1/2” |
15.9 |
255 |
≤0.01 |
13.3 |
1.98 | √ |
C |
| AKY-110R1-1/2C-1.0x | 110 | 1.0 | 1/2” | 20.9 | 240 | ≤0.05 |
14.0 |
1.67 | — | C |
| AKY-110R1-1/2TC-1.0x | 110 | 1.0 | 1/2” | 20.9 | 240 |
≤0.05 |
14.0 |
1.67 | √ |
C |
| AKY-110R1-1/2C-2.0x | 110 | 2.0 | 1/2” | 32.8 | 201 | ≤0.01 |
11.0 |
0.66 | — | C |
| AKY-110R1-1/2TC-2.0x | 110 | 2.0 | 1/2” | 32.8 | 201 |
≤0.01 |
11.0 |
0.66 | √ |
C |
| AKY-110R1-1/2C-3.0x | 110 | 3.0 | 1/2” | 49.2 | 220 | ≤0.01 |
11.0 |
0.44 | — | C |
| AKY-110R1-1/2TC-3.0x | 110 | 3.0 | 1/2” | 49.2 | 220 |
≤0.01 |
11.0 |
0.44 | √ |
C |
| AKY-110R1-1/2C-4.0x | 110 | 4.0 | 1/2” | 44.7 | 210 | ≤0.01 | 7.5 | 0.22 | — | C |
| AKY-110R1-1/2TC-4.0x | 110 | 4.0 | 1/2” | 44.7 | 210 |
≤0.01 |
7.5 | 0.22 | √ |
C |
| AKY-110R1-1/2C-6.0x | 110 | 6.0 | 1/2” | 67.1 | 233 | ≤0.01 | 7.5 | 0.15 | — | C |
| AKY-110R1-1/2TC-6.0x | 110 | 6.0 | 1/2” | 67.1 | 233 |
≤0.01 |
7.5 | 0.15 | √ |
C |
