2/3 HR TELECENTRIC LENS
| Model Name |
WD
(mm)
|
Magnification
(x)
|
IF
|
Effective Fno |
O/I
(mm)
|
TV Distortion
(%)
|
Resolution
(μm)
|
DOF
(mm)
|
Coaxial Light
|
Mount |
| AKY-65R2-2/3C-0.5x | 65 | 0.5 | 2/3” | 9.5 | 173 | ≤0.01 | 12.7 | 3.03 | — | C |
| AKY-65R2-2/3TC-0.5x | 65 | 0.5 | 2/3” | 9.5 | 173 |
≤0.01 |
12.7 | 3.03 | √ |
C |
| AKY-65R2-2/3C-0.8x | 65 | 0.8 | 2/3” | 9.9 | 172 | ≤0.02 | 8.3 | 1.24 | — | C |
| AKY-65R2-2/3TC-0.8x | 65 | 0.8 | 2/3” | 9.9 | 172 |
≤0.02 |
8.3 | 1.24 | √ |
C |
| AKY-65R2-2/3C-2x | 65 | 2.0 | 2/3” | 13.1 | 163 | ≤0.02 | 4.4 | 0.26 | — | C |
| AKY-65R2-2/3TC-2x | 65 | 2.0 | 2/3” | 13.1 | 163 |
≤0.02 |
4.4 | 0.26 | √ |
C |
| AKY-65R2-2/3C-4x | 65 | 4.0 | 2/3” | 17.3 | 187 | ≤0.02 | 2.9 | 0.09 | — | C |
| AKY-65R2-2/3TC-4x | 65 | 4.0 | 2/3” | 17.3 | 187 |
≤0.02 |
2.9 | 0.09 | √ |
C |
| AKY-65R2-2/3C-6x | 65 | 6.0 | 2/3” | 25.9 | 202 | ≤0.01 | 2.9 | 0.06 | — | C |
| AKY-65R2-2/3TC-6x | 65 | 6.0 | 2/3” | 25.9 | 202 |
≤0.01 |
2.9 | 0.06 | √ |
C |
| AKY-110R2-2/3C-0.5x | 110 | 0.5 | 2/3” | 9.5 | 263 | ≤0.02 | 12.7 | 3.03 | — | C |
| AKY-110R2-2/3TC-0.5x | 110 | 0.5 | 2/3” | 9.5 | 263 |
≤0.02 |
12.7 | 3.03 | √ |
C |
| AKY-110R2-2/3C-0.8x | 110 | 0.8 | 2/3” | 11.0 | 256 | ≤0.01 | 9.2 | 1.37 | — | C |
| AKY-110R2-2/3TC-0.8x | 110 | 0.8 | 2/3” | 11.0 | 256 |
≤0.01 |
9.2 | 1.37 | √ |
C |
| AKY-110R2-2/3C-2x | 110 | 2.0 | 2/3” | 13.1 | 258 | ≤0.02 | 4.4 | 0.26 | — | C |
| AKY-110R2-2/3TC-2x | 110 | 2.0 | 2/3” | 13.1 | 258 |
≤0.02 |
4.4 | 0.26 | √ |
C |
| AKY-110R2-2/3C-4x | 110 | 4.0 | 2/3” | 20.9 | 260 | ≤0.01 | 3.5 | 0.10 | — | C |
| AKY-110R2-2/3TC-4x | 110 | 4.0 | 2/3” | 20.9 | 260 |
≤0.01 |
3.5 | 0.10 | √ |
C |
| AKY-110R2-2/3C-6x | 110 | 6.0 | 2/3” | 38.5 | 288 | ≤0.03 | 4.3 | 0.09 | — | C |
| AKY-110R2-2/3TC-6x | 110 | 6.0 | 2/3” | 38.5 | 288 |
≤0.03 |
4.3 | 0.09 | √ |
C |
