1/2 SR TELECENTRIC LENS
| Model Name |
WD
(mm)
|
Magnification
(x)
|
IF
|
Effective Fno |
O/I
(mm)
|
TV Distortion
(%)
|
Resolution
(μm)
|
DOF
(mm)
|
Coaxial Light
|
Mount |
| AKY-65R2-2/3C-0.5x | 65 | 0.5 | 2/3” | 9.5 | 173 | ≤0.01 | 12.7 | 3.03 | — | C |
| AKY-40R1-1/2C-1x | 40 | 1.0 | 1/2” | 10.9 | 105 | ≤0.02 | 7.3 | 0.87 | — | C |
| AKY-40R1-1/2TC-1x | 40 | 1.0 | 1/2” |
10.9 |
105 |
≤0.02 |
7.3 | 0.87 | √ |
C |
| AKY-40R1-1/2C-1.5x | 40 | 1.5 | 1/2” | 12.5 | 105 | ≤0.02 | 5.6 | 0.45 | — | C |
| AKY-40R1-1/2TC-1.5x | 40 | 1.5 | 1/2” |
12.5 |
105 |
≤0.02 |
5.6 | 0.45 | √ |
C |
| AKY-40R1-1/2C-2x | 40 | 2.0 | 1/2” | 13.4 | 96 | ≤0.01 | 4.5 | 0.27 | — | C |
| AKY-40R1-1/2TC-2x | 40 | 2.0 | 1/2” |
13.4 |
96 |
≤0.01 |
4.5 | 0.27 | √ |
C |
| AKY-40R1-1/2C-3x | 40 | 3.0 | 1/2” | 17.0 | 107 | ≤0.05 | 3.8 | 0.15 | — | C |
| AKY-40R1-1/2TC-3x | 40 | 3.0 | 1/2” |
17.0 |
107 |
≤0.05 |
3.8 | 0.15 | √ |
C |
| AKY-40R1-1/2C-4x | 40 | 4.0 | 1/2” | 18.5 | 104 | ≤0.01 | 3.1 | 0.09 | — | C |
| AKY-40R1-1/2TC-4x | 40 | 4.0 | 1/2” |
18.5 |
104 |
≤0.01 |
3.1 | 0.09 | √ |
C |
| AKY-40R1-1/2C-6x | 40 | 6.0 | 1/2” | 27.7 | 118 | ≤0.02 | 3.1 | 0.06 | — | C |
| AKY-40R1-1/2TC-6x | 40 | 6.0 | 1/2” | 27.7 | 118 |
≤0.02 |
3.1 | 0.06 | √ |
C |
| AKY-40R1-1/2C-8x | 40 | 8.0 | 1/2” | 37.0 | 131 | ≤0.02 | 3.1 | 0.05 | — | C |
| AKY-40R1-1/2TC-8x | 40 | 8.0 | 1/2” | 37.0 | 131 |
≤0.02 |
3.1 | 0.05 | √ |
C |
